Model 5500 (10T)

Our Model 5500 (10T)

The model 5500 can hold 10 tonnes and has been expertly designed as a front-loading trailer. To empty the trailer, a single rear door is hinged sideways and folds back onto the side of the trailer, this prevents the door sticking into the muck heap when tipped. It comes in the standard colour of Mid Brunswick Green.

  • Armstrong & Holmes Trailer Icon

    Designed as a front loading trailer

    The front headboard folds down over the drawbar.

  • Armstrong & Holmes Ramp Icon

    Easily Accessible Ramp

    The weight is taken by two tension springs, so raising and lowering the ramp requires little effort.

  • Armstrong & Holmes Welding Mask Icon

    Quality Materials

    The ramp is made in non-slip alloy plate with alloy treads.

  • Armstrong & Holmes Brake Icon

    Reliable Fittings

    Lights, hydraulic brakes and a handbrake are fitted as standard. Options available include wide tyres and canopy. On some models, there is also an option of a twin axle, front extension ramp and rear loading. See our add-ons >

Model 5500 (10T) Specifications

Armstrong & Holmes Dimensions Side Icon
Armstrong & Holmes Dimensions Back Icon


Body Length

5.50m / 18' 0"ft

Body Width

2.88m / 7' - 6"ft

Body Height

1.88m / 6' - 2"ft

Overall Length

6.85m / 22' - 6"ft

Overall Width

2.44m / 8' - 0"

Overall Height

3.15m / 10' - 4"ft

Tipped Height

6.60m / 21' - 8"ft



Capacity: 22.75m³ / 805 ft³
Hydraulic Oil: 19.5 litres / 4.28 gallons


Unladen Weight: 3450


Number of Axles: 2

Request a quote for the Model 5500 (10T) farm trailer
